AGM PVS-14 3APW Gen3 AutoGated White Phos Monocular Night Vision

Product image 1
Product image 2
Product image 3

AGM PVS-14 3APW Gen3 AutoGated White Phos Monocular Night Vision

AGM PVS-14 3APW Gen3 AutoGated White Phos Monocular Night Vision

American Made, Gen 3, Auto-Gated, 2000+ FOM.  The 3APW is one of the high end units available from AGM.

At ODGG, several core members of our training group have used both binos and monos extensively.  There are benefits and drawbacks of both.  But when we're talking extended time under NODs and moving through varied terrain -- a monocular is way more comfortable over time and allows you to maintain depth perception.

You could save money on the NW1 or 3AL3 units that AGM offers, but if you can swing it -- the 3APW is going to offer you some of the best-in-class performance for under $5k.

Specs:

  • Image Intensifier Tube  Gen 3 Auto-Gated "3APW"
  • Resolution  64-72 lp/mm
  • Field of view cleanness by zone  Gen 3 IIT 3APW is highest performing and the cleanest Gen 3 IIT made by L3 and Elbit
  • Magnification  1x (3x and 5x optional)
  • Lens System  27 mm; F/1.2
  • FOV  40°
  • Focus Range  0.25 m to infinity
  • Diopter Adjustment  -6 to +2 dpt
  • Led Indicators  Low battery; IR On; Excessive light conditions
  • Infrared Illuminator  Yes
  • Manual Gain Control  Yes
  • Bright Light Cut-Off  Yes
  • Automatic Shut-Off System  Yes
  • Battery Type  One AA Alkaline
  • Battery Life (Operating)  Up to 40 hours at 20°C
  • Operating Temperature Range  -51° C to +49° C (-60° F to 120° F)
  • Storage Temperature Range  -51° C to +85° C (-60° F to 185° F)
  • Weight  0.35 kg (12.4 oz)
  • Overall Dimensions  114 x 63x 69 mm (4,5 x 2,5 x 2,7 in)
  • Package Includes  Head Mount Assembly, Brow Pad, Eye Cup, Helmet/ Head Mount Adapter, System Soft Carrying Case, Daylight Filter, Shoulder Strap, Lens Paper, Diopter Lens Cap, Sacrificial Window, Demist Shields, Operator’s Manual, Battery
$6,032.10

Original: $20,107.00

-70%
AGM PVS-14 3APW Gen3 AutoGated White Phos Monocular Night Vision

$20,107.00

$6,032.10
